PLC Control Glass Edging Machine For Glass Production Line,Glass Double Edging Polishing Machine,Glass Double Edger

Short Description:

Glass Edging Machine: Glass Double Edger Production Line Glass Transmission Rate: 0.5~8m/min Glass Diagonal Error:: ±0.5mm/㎡ Thickness Of Process Glass: Standard 3~25mm Number Of Motors: 24 Certification: CE/ISO9001:2008 PLC Control Glass Edging Machine For Glass Production Line,Glass Double Edging Polishing Machine,Glass Double Edger Quick Details Condition: New Machine Type: Glass double edger production line Production Capacity: 12 sets/month Place of Origin: Guangdong, China ...


Product Detail

Product Tags

Glass Edging Machine: Glass Double Edger Production Line Glass Transmission Rate: 0.5~8m/min
Glass Diagonal Error:: ±0.5mm/㎡ Thickness Of Process Glass: Standard 3~25mm
Number Of Motors: 24 Certification: CE/ISO9001:2008

PLC Control Glass Edging Machine For Glass Production Line,Glass Double Edging Polishing Machine,Glass Double Edger

Quick Details

  • Condition: New
  • Machine Type: Glass double edger production line
  • Production Capacity: 12 sets/month
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: SAINT BEST
  • Model Number: SBT-BYL4525
  • Voltage: 220/380V/480 50Hz/60Hz 3P
  • Power(W): 103Kw
  • Dimension(L*W*H): 18500*10000*2800mm
  • Weight: 18000kg
  • Certification: CE
  • Warranty: 1 Year
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Grinding motor supplier: Shanghai ABB
  • Glass transmission rate: 0.5~34m/min
  • Thickness of process glass: Standard 3~25mm
  • Width of glass chamfering: 0~3mm
  • Number of motors:24
  • Error of glass chamfering width: ±0.2mm/m
  • Error of glass paralle: ±0.2mm/m
  •  6 Motors Glass Double Pencil Round Edge Grinding Machine / Pencil Glass Double Edge Edger

Packaging & Delivery

Packaging Details: export standard package
Delivery Detail: Shipped in 60 days after payment

 Product Description

SBT-BYL4525(24 motors)



1. The first machine:SBT-BYS4524

and

2. The second machine:SBT-BYS2524



the number of motors :24 motors (depends on the customer's requirement)

the width of glass chamfering : 0~3mm

The thickness of process glass :3~25mm
The error of glass parallel: ±0.2mm/m

The error of glass chamfering width: ±0.2mm/m
Glass diagonal error : ±0.5mm/㎡

Width positioning error: ±0.1mm/㎡
Glass transmission rate : 0.5~8m/min

Power source:380/3ph/50Hz ( depends on the customer's requirement)

Glass double pencil edger,6 motors glass double pencil round edge grinding machine,8 motors glass double pencil round edge grinding machine,10 motors glass double pencil round edge grinding machine,Glass double round edging machine,10 motors glass pencil round double edge grinding machine

Arrangement of grinding wheels and distribution diagram of motor power

PLC Control Glass Edging Machine For Glass Production Line,Glass Double Edging Polishing Machine,Glass Double Edger

Arrangement of grinding wheel and distribution diagram of motor power

No.1          No.2         No.3        No.4      No.5     No.6     No.7    No.8    No.9     No.10   No.11     No.12

100#         140#         180#         240#    10S40   240#   10S40   240#   240#    10S40   10S40   10S40

Diamond   Diamond   Diamond  Resin   Taxus   Resin   Taxus    Resin   Resin   Taxus   Taxus   Taxus

wheel        wheel         wheel      wheel    wheel   wheel    wheel   wheel   wheel   wheel   wheel   wheel

PLC Control Glass Edging Machine For Glass Production Line,Glass Double Edging Polishing Machine,Glass Double Edger



Main Features

The minimal size of the common process glass is 160mm*160mm,minimal thickness 2mm.The thickest size depends on the requirements and the quality of grinding wheel..Glass double pencil edger,6 motors glass double pencil round edge grinding machine,8 motors glass double pencil round edge grinding machine,10 motors glass double pencil round edge grinding machine,Glass double round edging machine,10 motors glass pencil round double edge grinding machine,12 motors glass double pencil round edge grinding machine,14 motors glass double pencil round edge grinding machine.

This machine has the advanced structures,precision components,exquisite assembly technology,good fittings,stable property,excellent quality,easy operation and simply maintenance.

Processing glass diagonal error within 0.5 mm,parallelism error within 0.1mm,chamfering balance,clear angles,no collapse edge, round edge phenomenon.10 Motors Glass double pencil edger,8 motors Glass double pencil edger,6 motors Glass double pencil edger,12 Motors Glass double pencil edger,14 motors Glass double pencil edger.

It is suitable for processing all kinds of high-grade sealed insulating glass and appliances glass.Can be extended the laser code then identify the automatic control.Glass Straight-line Turning Table,Glass automatic Turning Table,Glass Automatic Turning Table.



3. L-shape transfer table (SBT-BYL4525)



SBT-BYL4525 L-shape glass double-deck turning table is bilateral glass edge grinding machine ( right angle arrangement) in the middle of the directional control unit. The machine transmission device is divided into two layers, the bottom and top layers of transmission direction perpendicular to each other. The processing glass enters through the feed end and is processed by the first glass double straight edge grinding machine. After this, the glass is turned 90degree through the glass automatic reversing station. And then it is delivered to the feed end of the second set of glass double straight edge grinding machine and complete the other two sides edge grinding processing.Transittransport all actions by the first double edger control, without artificial assistance.glass tempering furnace,glass double edging machine,glass straight line beveling edging machine,glass straight line edging machine,glass straight line multilevel edging machine,glass washing machine,glass drilling machine,glass irregular shape machine,glass automatic sandblasting machine,glass chamfering machine and glass automatic cutting machine,glass automatic loading machine.



Main Technical Parameters:



No. Items Parameters Remarks
1 Max glass size/mm 4500×2500 Can be customized according to customer requirements
2 Min glass size/mm 200×200

The minimum size can transit

:70mm×70mm

3 Thickness of glass/mm 3-25mm
4 Glass transmission rate 0.5-34 m/min
5 power 3.5 KW
6 Power source AC380V 50HZ
